gaugeART Chroma 52mm CAN Gauge

$389.00
SKU
GAU-44-001
New Product!

This product begins shipping Dec 1.



The gaugeART Chroma is an upgrade to the popular gaugeART CAN Gauge, which displays real-time data from your engine management system. The gauge features a stunning, high-resolution, full-color AMOLED touchscreen deliverying more information, greater customization, and improved visibility in the same compact 52mm package.

Designed to give drivers instant access to critical engine data with out the need for a larger display, the new Chroma CAN Gauge features a 466x466 pixel display with 16.7 million colors, 700 nits brightness, and an ultra wide 178° viewing angle, ensuring excellent clarity and visibility from almost any position.

Display up to eight real-time engine parameters simultaneously across ten fully customisable pages, allowing you to prioritise the information that matters most. From RPM and boost pressure to oil pressure, coolant temperature and more, the new touchscreen interface makes monitoring your engine easier than ever.

Customizable touchscreen buttons and trim options provide greater flexibility, while configuration through a web-based application eliminates the need to download a dedicated smartphone app.

The Chroma CAN Gauge is compatible with these popular ECUs:

  • AEM EMS Series 2
  • AEM Infinity
  • Haltech
  • Hondata KPRO4 & S300
  • Link (G4+, G4X, G5, and later)
  • MegaSquirt MS3
  • MoTeC M1 Series
  • ProEFI Pro
  • ScienceofSpeed AEM Infinity (discontinued)
  • ScienceofSpeed Link G4X
  • Syvecs S6, S6Plus, S8
  • others listed on the gaugeART website
  • click for complete list and channels that these ECUs support



Features

  • AMOLED display: bright, full-color display.
  • Touchscreen: intuitively tap between pages and functions.
  • Dual-core processor: handles complex, full-featured gauges.
  • High resolution: fine resolution allows sharp text and gauges.
  • Improved WiFi configuration: configure wirelessly with any mobile device or laptop. No app required.
  • Highly configurable: Create up to 10 pages with a variety of gauge layouts (dial, vertical bars, horizontal bars, and digital gauges). Choose between colors, labels, and data range.
  • Warnings: choose to have the gauge change a distinctive color at a certain low or high warning point. A warning page can also be displayed when a certain high or low warning point is reached.
  • CAN Keypad: For compatible ECUs, use the on-screen CAN keypad to trigger switched functions like anti-lag, launch control, traction control, and clearing faults, and to adjust trim levels for functions like boost control, traction control, and throttle responsiveness.

Display Data Your Way

Create up to 10 pages of various layouts (dial, vertical bars, horizontal bars, and digital gauges).

Touchscreen

The gauge features a touchscreen that allows navigation between screens and settings pages.

Responsive Gauges

Configure the gauge colors from low to high range and allow the gauge to change colors when a low or high warning point is exceeded.

Warning Pages

Configurable warning pages are triggered when a low or high point is exceeded.

CAN Keypad Switch

For compatible ECUs (click for list of ECUs with CAN Keypad function), use the on-screen switch to trigger switched functions like anti-lag, launch control, traction control, and clearing faults.

CAN Keypad Trim

For compatible ECUs (click for list of ECUs with CAN Keypad function), use the on-screen trim to adjust trim levels for functions like boost control, traction control, and throttle responsiveness.

Includes

  • gaugeART Chroma CAN Gauge
  • mounting bracket & hardware
  • data & power cable

Options

standard cable (41-001.02): the standard cable is 8′ long and includes two shielded pair wires (power, ground, CAN H, and CAN L) and one wire for illumination control. It is meant for ECUs or ECU harnesses with out specific CAN connectors – or for you to install your ECU’s CAN connector to. This cable is used with all ScienceofSpeed-manufactured harnesses for AEM Infinity, AEM EMS Series 2, and Hondata KPRO 4 ECUs.

ECU specific cables: for ECUs or ECU harnesses that have specific CAN connectors (AEM-manufactured harnesses for Infinity & ProEFI), these 5′ long cables have ECU specific connectors pre-installed. If you have a harness for an AEM Infinity not manufactured by AEM or ScienceofSpeed - check with that manufacture on what connector was installed.

Select the correct cable for your ECU:
  • AEM EMS 2 & AEM EMS 4: 41-001.02
  • AEM Infinity with female DTM-4 in harness: 41-001.12
  • Haltech ECUs w/ plug-and-play DTM-4 connector: 41-001.18
  • Hondata KPRO V4 & S300 V3: 41-001.02
  • Link ECUs with female DTM-4 connector: 41-001.19
  • ScienceofSpeed AEM Infinity - NSX & S2000 (discontinued): 41-001.02
  • ScienceofSpeed Link ECU - NSX, 1991-05: 41-001.02
  • ScienceofSpeed Link ECU - S2000, 2000-05: 41-001.19
  • ScienceofSpeed Link ECU - S2000, 2006-09: 41-001.02
  • Other supported ECUs not listed: 41-001.02
Optional cables:
  • extension cable: if your ECU is more than 5′ away from where your gauge will be mounted – an optional 5′ extension cable (total distance 10′) is available.
  • daisy chain cable: if you will be using more than one gaugeART CAN Gauge – an optional 8″ daisy chain cable will link the two gauges together.
Fuse box connectors:
  • The gaugeART CAN Gauge needs power, ground, CAN H, and CAN L illumination connections.
  • If you are connecting this gauge to a ECU specific cable (41-001.12, 41-001.18, 41-001.19) this connector provides the power, ground, and CAN H & L. The only wire that will need to be terminated is for illumination.
  • If you are connecting this gauge to a ScienceofSpeed accessory connector (used in all 1991-05 NSX and 2006-09 S2000 kits) you will need the standard unterminated cable (41-001.02). This cable terminates to the supplied accessory connector using the terminals included in the ECU kit. The illumination circuit will need to be terminated.
  • For illumination (and power for ECUs that do not have a plug and play connector or accessory connector, like Hondata KPRO 4) the factory fuse may be used. Connect to the fuse box connections using standard 1/4" female spade connectors or optional fuse box connectors. Note that if the fuse box is used, each circuit must be fused with an in-line fuse (5A).
