Titan 7 T-C5 Forged Wheels - NSX, 1991-05
$0.00
SKU
epp-2564-X
The T-C5 is the launch of our Titan 7's Forged for All manufacturing!
Building on the success of our catalog, we now offer our rendition of the classic 5-spoke wheel design to our existing wheel lineup. The 5-spoke design is very simple and elegant and leave it to the Titan 7 team to pack the wheel with technical features that take our “Forged for All” ideology to the next level. A full face design was chosen to give the wheel an excellent base for strength and rigidity. Next, we took the popular "I–Beam” spoke construction beyond the competition by connecting the machining work from the hub, spoke, and rim. This is a first for any wheel manufacturer. In keeping with our commitment to both lightness and strength, a back rigid spoke tracer was employed for additional strength and stiffness. You can see a sliver of material that goes a long way for performance. Extensive machining was also employed on all available areas to remove material for final weight optimization. All of this was made possible by applying 10,000 Tons of industry leading forging force. Standard Titan 7 features like our original beefed up inner rim flange for durability, bead seat knurling for traction, and contrast machined branding for authenticity lets your competition know you are serious with your vehicle build. Generation 2 Series Wheels DO NOT include Center Caps. Authentic performance from Titan 7. Forged for All.
Wheel Specifications:
front: 17x8.0+37, rear: 18x10.0+40
Brake clearance:
Clears ScienceofSpeed Brembo Pista, Brembo GT, Brembo Indy, Stoptech.
Weight (approximate):
Front: 17.8 lbs, Rear: 21.2 lbs
Recommended tire sizes (street):
front: 215/40-17 & rear: 265/35-18 (click here for available options) or
Recommended tire sizes (track):
front: 235/40-17 & rear: 275/35-18 (click here for available options)
Note: these are intended for track use - front size is oversized and may result in rubbing on inner fender panels & fender liner. Some modification like flaring of the fender may be required.
Features
- Fully forged with industry-leading 10,000-ton press.
- Designed exclusively for the first generation NSX: NSX-specific sizing, offset, and bolt center.
- Everything from design, tooling, forging, machining, heat treatment, surface finishing, and testing is all done in house with no outsourcing.
- Properly designed offsets eliminate the "tucked" look of the factory wheels with the need for spacers.
- Tire traction improving knurled bead lock.
Includes
- Front & rear set of wheels.
- Set of 4 CNC-machined aluminum valve stems, black anodized.
- Hub-centric centering rings.
Options
Available Finishes:
- Satin Machine Black
Optional Center Caps:
CNC-machined aluminum center caps, color-matched to the wheel, are available as an optional upgrade.
Optional lug nuts:
These wheels require 60-degree seat lug nuts, typical for aftermarket wheels. Factory lug nuts are not compatible. Click here for recommended lug nuts.
